Austin Organ

3 manuals, 55 ranks, 2,817 pipes

3268788201_c7daee9a72_oSpecifications

Great – unenclosed

8’ Principal
8’ Bourdon
8’ Gemshorn
4’ Octave
4’ Spitzfloete
2’ Waldfloete
II Rauschquinte
III-V Fourniture
8’ Trompete (ext. pedal Posaune)
Chimes (old organ)

Swell – enclosed

16’ Gedeckt
8’ Geigen
8’ Hohlflote
8’ Gambe
8’ Gambe Celeste (tenor c)
4’ Principal
4’ Rohrfloete (ext. Gedeckt)
2’ Blockflote
III Plein Jeu
16’ Fagotto
8’ Trompette
4’ Clarion
8’ Vox Humana (old organ)
Tremulant

Antiphonal – console

8’ Holzgedeckt
4’ Principal
2’ Fifteenth
III Mixture
8’ Trumpet

Positiv – enclosed

8’ Nason Flute
8’ Flauto Dolce
8’ Flute Celeste (tenor c)
4’ Prestant
4’ Koppel Floete
2 2/3’ Nazard
2’ Octav
1 3/5’ Tierce
III Cymbal
8’ Krummhorn
Tremulant

Pedal

32’ Resultant (Bourdon)
16’ Principal
16’ Bourdon (ext. Great)
16’ Gemshorn (ext. Great)
16’ Gedeckt (Swell)
8’ Octave
8’ Spitzfloete
8’ Rohrgedeckt (Swell)
4’ Choral Bass
4’ Floete (ext. Spitzfloete)
III Mixture
16’ Posaune
16’ Fagotto (Swell)
8’ Posaune (ext.)
4’ Krummhorn (Positiv)

Antiphonal Pedal – console

16’ Gedeckt (ext.)
8’ Holzgedeckt

Couplers

Swell to Great 16 8 4
Positiv to Great 16 8 4
Antiphonal to Great 8
Great Unison Off
Swell to Swell 16 4
Positiv to Swell 8
Swell Unison Off
Positiv to Positiv 16 4
Swell to Positiv 16 8 4
Great to Positiv 8
Antiphonal to Positiv 8
Positiv Unison Off
Great to Pedal 8
Swell to Pedal 8 4
Positiv to Pedal 8 4
Antiphonal to Pedal 8
Selective optional control. Pedal stops to any manual piston.

Combinations

Great 7 adjustable pistons
Swell 7 adjustable pistons
Positiv 7 adjustable pistons
Antiphonal 3 adjustable pistons
Pedal 6 adjustable toe studs
General 14 adjustable pistons
10 duplicating toe studs
Great to Pedal reversible piston and toe stud
Swell to Pedal reversible piston and toe stud
Postiv to Pedal reversible piston and toe stud
Swell to Great reversible piston
Positiv to Great reversible piston
Tutti reversible piston and toe stud with indicator light
General Cancel which cancels Tutti as well
Canceller bars over each group of stop keys

Mechanicals

Balanced Swell expression pedal with four-light indicator
Balanced Positiv expression pedal with four-light indicator
Balanced Crescendo pedal with four-light indicator
